Characteristics
■ 122GHz Frequency FMCW radar system.
■ Measurement application in liquids, solids.
■ Chemical industry reaction tanks, environment applications, also in steam.
Specifications
ANL/AiW-4120MP60 enhanced G2-¼ plastic housing version
Non-contact Smart Radar Level Gauges Datasheets
| ANL/AiW-4120MP60 | Housing/Antenna material POM | Housing/Antenna material PTFE | Note |
|---|---|---|---|
| Max. measuring range | 10M/18M/20M/30M/40M | 40M only for HART/IO-Link/APL version | |
| Near blind spot | < 100mm from the Antenna down surface | ||
| Tx/Rx frequency | Tx/Rx frequency 120 to 125GHz Dynamic FM Sweep Bandwidth 1~5GHz (The adjustment FM range can be customized according to the ISM requirements of the customer’s region) | ||
| Meas. Principle | FMCW Radar System, TX power -3dBm (not included antennas), RX Input compression point -20dBm & Gain 10dB (not included antennas) | ||
| Lens Antenna Medium | POM Φ60mm | PTFE Φ60mm | Material exposed to tank atmosphere |
| Antenna beam / Gain | Beam angle 6°/ Gain 25.8dB | Beam angle 4.5°/ Gain 31.7dB | |
| Meas. Resolution | 0.1mm (<10m range) | Depends on the bandwidth and range | |
| Meas. Accuracy | ±1mm (<10m range) / ±2mm (18m/20m range) / ±4mm (30m/40m range) | ||
| Ambient temperature | -40 … +85 °C | -40 … +85 °C | |
| Process temperature | -40°C … +120°C | -40°C … +120°C | |
| Process pressure | -0.1 ~ +2.5MPa | -0.1 ~ +2.3MPa | |
| Process connection | Thread G2-¼ or NPT | ||
| Signal output | 4-20 mA (regular), or/ 4-20 mA/HART7, or/ (RS-485) Modbus, or/ IO-Link, or/ Ethernet-APL (option issue) | ||
| Variables influencing meas. accuracy | Specifications for the digital measured value： Temperature drift - Digital output: ±1mm/10K relating to the max. measuring range or max. 15 mm Additional deviation through electromagnetic interference acc. to EN-61326: < ±10 mm Specifications apply also to the current output Temperature drift - Current output: ±0.02%/10K relating to the 16.7 mA span or max. ±0.2% Deviation in the current output due to digital/analogue conversion Non-Ex and Ex-ia version: < ±1μA; Ex-d-ia version: < ±1μA Additional deviation through electromagnetic interference acc. to EN-61326: < ±150μA | ||
| Indication/Adjustment (LOI) | 1. 160x80 LCD FSTN RGB backlight monitor adapter with keyboard module, operation Temp. -20°C … 70°C. or 128x64 OLED monitor adapter with keyboard module, operation Temp. -55°C … 80°C. (option) or 230x240 LCD TFT colors monitor adapter with keyboard module, operation Temp. -20°C … 70°C. (option only for 4-wrie system) 2. (APP) Radar MobileManager via BT wireless connection 3. (PC software) Radar PCManager /or Via a PC with PACTware/DTM (an interface converter AiW-305 USB CONNECT is required) | ||
| Indication/Adjustment (LOI) | (APP) connecting RadarMobileManager via BT wireless connection | ||
| Meas. output update rate | < 3s. (Run-up time to get first Reading: <5s forRS485; <45s for mA loop) @UB=16VDC | ||
| Power supply | 16V … 40 VDC / Load resistor > 500Ω (for mA version), 12V… 36VDC (for RS485 version) | ||
| Wireless communication | Bluetooth 5.0 (Bluetooth 4.0 LE compatible), communication range 40m, in rainy day 20m | ||
| Approvals | CLEx/CNEx: Ex ia IIC T6 Ga IP67; Ex d IIC T6 Gb IP67 | ||
| Housing | Plastic POM or PTFE, IP67 / IP68 | ||
| Applications | Liquids, solids, and corrosive environment applications | ||
| Document Download |  AiW-4120MPMC_120GHz Operation_Manual_DY0723 |
SERVICE CONTACT: 86-13799977915, 86-18965063391(TECHNICAL SUPPORT), 86-18106067295(AFTER SALE SERVICE)
ALTHOUGH WE HAVE RECONCILED THE CONTENTS OF THE MANUAL WITH DESCRIPTION OF INSTRUMENT, THERE MAY STILL BE CHANGES WE CANNOT ENSURE THAT IT IS FULLY CONSISTENT. THE CONTENT WILL BE CHECKED AND CORRECTED IN AN ORDERLY, AND THE ERRATA WILL BE IN SUBSEQUENT RELEASES. WE WELCOME USERS TO MAKE VARIOUS SUGGESTIONS FOR IMPROVEMENT. [TECHNICAL DATA SUBJECT TO CHANGE]
Dimensions
