Benefits
- Easy to apply in the small tank with fast level change
- Economical solution for high accuracy measuremment
- FMCW technology applied to get better performance than pulse
Specifications
| Frequency | 23.5~26.5GHz, 3GHz(FMCW width) |
| Range | 0.3~35m；(max<45M) |
| Resolution | 0.02mm |
| Accuracy | ±3mm |
| Beam angle | 16° |
| Dimension | 235mm x 100mm x 100mm (no flange) |
| Connection | G 1-½ "A –NPT (for flange) |
| Antenna Type | Conical lens antenna, PTFE (20dBi dynamic gain) |
| Signal Output | 4..20mA/HART/RS485/Profibus PA/Wi-Fi/Bluetooth |
| Communication | 4-20mA/HART/MODBUS |
| Failure Output | 22mA/20.5mA (can be set) |
| Process Temp | -40 ~85°C |
| Humidity | ≤95%RH |
| Pressure | -0.5 ~ 5.0MPa |
| Power Supply | 16 ~ 45VDC, 2-wire /12~ 36VDC, 4-wire/110-250VAC |
| Adjustment | PC software / APP (only for 4-wire) / Tank Side Indicator 160x80 Dots LCD / 4 key |
| Casing | aluminum alloy |
| Connection | M20x1.5 (φ6...12mm) |
| Protection | IP67 |
Dimensions
Overview
ANL-9107 24GHz FMCW radar level Gauges Overview
Housing Versions
The housings are available as single chamber or double chamber version in plastic, stainless steel or aluminum. They are available with protection ratings up to IP 68, and the process seal is made of FKM, FFKM or graphite. For instruments with double chamber housing two supplementary electronics such as radio module or a power pack are available. You will find a complete overview of the available drawing in the Available enclosures: Housing Drawing.
Summary of the ANL-9107 model parameter table
Note:
* Under the condition of purging function, the process pressure should not exceed 1.5MPa.
** With a cooler, ANL-9107Nx Max. process temperature will be up to 450℃
Model selection guide for the ANL-9107 based on different process media characteristics
ANL-9107 : Guidelines on which model and antenna to select, depending on application
