ANL-8260-PCBA Pulse Radar PCBA Kits

26GHz pulse radar PCBA kits, is designed with unique FPGA accurate emission impulse control, strong frequency stability, reliability, and temperature compensation capability. OEM acceptable.

To order or inquire, please contact us


Quantity:
Price: 1.00 USD

Benefits

  • High reliability, high cost-effective, save your costs in the field
  • Suitable for industrial silos, tanks, vessels level measurement, and hydrological water level measurement
  • Support Wi-Fi, Bluetooth, APP, WeChat mini program wireless communication, remote communication
  • Support tank side meter
  • Option for mono TFT LCD and industry level colored TFT LCD
  • OEM acceptable, easy to customize and integrate

Specifications

Frequency26GHz
Range10m/30m/70m/80m
Resolution1mm
Accuracy±10mm
Spread spectrum3.579545MHz ±30ppm
Blind area0.6m
Interval time≥1s
Response time≥5s
Beam angle<8°
Signal Output4-20mA output
CommunicationHART
Process Temp-40 ~ 85℃
Humidity≤95%RH
Pressure-1 ~ 10MPa, -10~20MPa (including enhanced flange structure)
Power Supply16-36VDC
Max load500Ω
Failure outputno change/22mA/20.5mA/4mA
Operation 160*80 dot LCD
Dimensions75mm×75mm×100mm
LanguagesChinese + English / Portuguese / Thai / Korean /  Japanese
CasingABS
Protective typeNo potting / transparent jelly gel potting

Dimensions
